Specification		SPM4500 (SGPM4500)	SPM5500 (SGPM5500)	SPM6500 (SGPM6500)	SPM7500 (SGPM7500)	SPM8500 (SGPM8500)
Capacity	Distance between columns	4,500 mm	5,500 mm	6,500 mm	7,500 mm	8,500 mm
	Distance between table surface & spindle nose	2,500 ~ 4,500 mm	4,000 ~ 5,500 mm	4,000 ~ 6,500 mm	4,000 ~ 7,500 mm	4,000 ~ 8,500 mm
	Table size	3,500 mm (138 in.)	4,500 mm	5,500 mm	6,500 mm	7,500 mm
	Spindle motor power	AC 75 ~ 105 kW	AC 105 kW	AC 105 ~ 150 kW
	Ram section	600 × 600 mm	600 × 600 / 630 × 630 mm	600 × 600 / 630 × 630 mm
Stroke	X-axis	6,000 ~ 20,000 mm	8,000 ~ 25,000 mm	8,000 ~ 25,000 mm	8,000 ~ 25,000 mm
	Y-axis	5,000 ~ 6,000 mm	6,000 ~ 7,000 mm	7,000 ~ 8,000 mm	8,000 ~ 9,000 mm	9,000 ~ 10,000 mm
	Z-axis	1,500 ~ 2,500 mm	1,500 ~ 3,000 mm	1,500 ~ 3,000 mm	1,500 ~ 4,000 mm
	W-axis	2,000 ~ 3,500 mm	3,000 ~ 4,500 mm	3,000 ~ 4,500 mm	3,000 ~ 5,500 mm	3,000 ~ 6,500 mm
Feed rate	X-axis	10,000 mm/min		10,000 mm/min
	Y-axis	10,000 ~ 15,000 mm/min		10,000 ~ 15,000 mm/min
	Z-axis	10,000 mm/min		10,000 mm/min
	W-axis	2,000 mm/min		2,000 mm/min
Control system		Siemens or Fanuc
Measuring system		Haidenhain or Fagor

*对于上述以外的定制规格，请联系我们。

• X, Y, W-axis telescopic cover
• Work light
• Patrol lamp (red, green, yellow)
• X & Z-axis telescopic cover
• Leveling block & anchor bolt

• Coolant supply unit (internal / external)
• Chip conveyor
• Automatic tool changer
• Automatic attachment changer
• Attachment
• Facing head
• Adapter
• Extractable and independent operator platform
• Renishaw probe system
• Laser tool measurement system
• Machine tools monitoring system(black box)
• Industrial camera with recorder
