Specification		SNVTM4050	SNVTM5060	SNVTM6070	SNVTM7085	SNVTM80100	SNVTM100120
Capacity	Max.Turning diameter	5,000 mm	6,000 mm	7,000 mm	8,500 mm	10,000 mm	12,000 mm
	Table diameter	4,000 mm	5,000 mm	6,000 mm	7,000 mm	8,000 mm	10,000 mm
	Max.Turning height	2,000 ~ 5,000 mm	3,000 ~ 6,000 mm	3,000 ~ 6,000 mm	4,000 ~ 9,000 mm	4,000 ~ 9,000 mm	4,000 ~ 9,000 mm
Stroke	X-axis	2,700 mm	3,200 mm	3,700 mm	4,450 mm	5,200 mm	6,200 mm
	Z-axis	1,000 ~ 2,000 mm	2,000 ~ 3,000 mm	2,000 ~ 3,000 mm	2,000 ~ 4,000 mm	2,000 ~ 4,000 mm	2,000 ~ 4,000 mm
	W-axis	2,000 ~ 4,000 mm	2,000 ~ 5,000 mm	2,000 ~ 5,000 mm	3,000 ~ 7,000 mm	3,000 ~ 7,000 mm	3,000 ~ 8,000 mm
Feedrate	X-axis	10,000 ~ 15,000 mm/min
	Z-axis	10,000 mm/min
	W-axis	2,000 mm/min
Milling spindle	Spindle motor power	22 ~ 45 kW	37 ~ 60 kW	37 ~ 60 kW
	Spindle speed	1,500 / 2,000 rpm
	Ram section	350 x 350 / 400 x 400	400 x 400	450 x 520
Turning table	Motor power	75 ~ 100 kW	100 ~ 150 kW	100 ~ 150 kW	150 ~ 200 kW
	Max.Turning speed	50 (100) rpm	30 (50) rpm	30 (50) rpm	20 (30) rpm	20 (30) rpm	20 rpm
	Max.Workpiece weight	50 ~ 80 ton	100 ~ 150 ton	100 ~ 200 ton	150 ~ 400 ton	150 ~ 400 ton	200 ~ 600 ton
Control system		Siemens or Fanuc
Measuring system		Heidenhain or Fagor

*상기 사양 외 주문제작 사양은 당사로 연락 바랍니다.

• 4 chucking jaw units
• X, W-axis telescopic cover
• Patrol lamp (red, green, yellow)
• Leveling block & anchor bolt
• Turning tool holder
• Boring bar

• Coolant supply unit (internal / external)
• Chip conveyor
• C-axis function
• Milling head
• Automatic tool changer
• Automatic attachment changer
• Attachment
• Adapter
• Extractable and independent operator platform
• Renishaw probe system
• Laser tool measurement system
• Machine tools monitoring system (black box)
• Industrial camera with recorder
